Cargador DC M7 Lipo 1-6S 10A 7-28V toolkit
Brand:
The M7 charger is smaller, lighter and almost as powerful as the M7AC charger. With a variety of different features such as balance charging and discharging. However, it can also be used as a signal measuring device or directly as a signal source in terms of PWM, PPM and SBUS signals.
Features:
Up to 300W charging power and maximum 15A charging current
Max. 300W discharge power
Multifunction device
Charger
Meter for voltage, resistance, PWM/PPM/SBUS signals
Playback of PWM/PPM/SBUS signals
Multilingual user interface including voice output
Upgradeable via USB
Various security controls
Technical Specifications:
Input Voltage:AC 100-240V, max. 100W
DC 7-35V, max. 20A
Charge Power:0.1-15A, 300W
Discharge Power:0.1-15A, 300W (Rec/Ext. Mode)
0.1-3A, 15W (Intern. Mode)
Charging Accuracy:<0.005V
USB A:5.0V@10W (or Upgrade)
Balance Current:800mA, 4.2V
Cells LiPo/LiFe/LiIon/LiHV1-6S
Cells: NiMH1-16S
Pb Battery Voltage:1-10S
Voltage:1.0V-5.0V, 1-6S
Display:IPS 2.4'' 320x240px LCD
TF Card:Supports 128MB to 16GB
Dimensions:112x73x38mm
Weight:245g
Measurement & Output:
MeasurementPWM880us-2200us, 20-400hz
PPM880us-2200us x8 CH, 20-50hz
SBUS880us-2200us x16 CH, 20-100hz
OutputPWM500us-2500us, 20-1000hz
PPM880us-2200us x8 CH, 50hz
SBUS880us-2200us x16 CH, 74hz
Power0.5-15A, 1-28V, Modus: CC+CV
Delivery:
1x M7AC-Charger
1x USB cable
1x Manual
