Traxxas TRX4 Ford Bronco 2021 Naranja

TRAXXAS TRX4 - 2021 Ford Bronco Scale and Off-Road Vehicle - ORANGE

A LEGENDARY OFF-ROADER RETURNS!

The legend has returned. After 25 years, the Bronco is back as Ford's highest-performing 4x4 and the most coveted SUV in the United States. Traxxas has recreated the highly anticipated Bronco with exceptional detail, offering you all the capability and versatility of the award-winning TRX-4. The Traxxas Bronco combines Ford-approved realism with class-leading performance so you can enjoy thrilling off-road adventures, no matter where the trail takes you.

Vehicle Specifications:

Overall length: 584 mm

Chassis length: 549 mm

Front track width: 249 mm

Rear track width: 249 mm

Ground clearance: 80 mm

Weight: 2.91 kg

Height: 239 mm

Wheelbase: 324 mm

Front shock length: 90 mm

Rear shock length: 90 mm

Front wheels: 1.9 x 1.02 (49 x 26 mm)

Rear wheels: 1.9 x 1.02 (49 x 26 mm)

Front tires: 118 x 48 mm

Rear tires: 118 x 48 mm

Approach angle: 52°

Departure angle: 49°

Breakover angle: 58°

Hex size: 12 mm

Speed control: XL-5 HV

Motor (electric): 21T, reverse rotation

Transmission: 2-speed (high/low), remote shifting

Gear pitch: 32P

Differential type: 4-speed, remote locking

Chassis structure/material: Steel ladder frame with nylon composite crossmembers

Brake type: Electronic hill hold assist

Drive system: Shaft-driven 4WD

Steering: Chassis-mounted servo

Servo: 2075X, metal gears

Transmitter: TQi? 2.4 GHz 4-channel transmitter

Receiver: 6533

Skill level: 1

Battery tray: 158.75 x 47 x 23/26 mm (length x width x height)

Motor Specifications:

Type: High-torque brushed motor

Size: 550

Weight: 390 g

Length: 78 mm (total), 57 mm (can)

Diameter: 38.9 mm

Turns: 21T (reverse rotation)

Voltage: 16.8 V

ESC Specifications:

Input voltage: 6-7 cell NiMH, 2-3S LiPo

Motor limit: 21 turns (size 550)

Max current - Forward: 100 A

Max current - Reverse: 100 A

Brake current: 60 A

Continuous current: 18 A

BEC voltage: 6.0 V DC

BEC current: 1 A

Low voltage detection (LVD): 2-stage indicators, switchable (on or off)

Thermal protection: Thermal shutdown

Single-button setup: Yes, Traxxas EZ-Set®

Profile selection:

Sport mode: 100% forward, 100% brakes, 100% reverse

Race mode: 100% forward, 100% brakes, no reverse

Training mode: 50% forward, 100% brakes, 50% reverse

Trail mode: 100% forward, 100% brakes, 100% reverse, optimized trail brake in neutral

Crawl mode: 100% forward, Instant 100% throttle, 100% brake in neutral

* Patented

Box Contents:

TRX-4 Ready-To-Race® model

Waterproof XL-5 HV electronic speed control

Reverse rotation Titan? 21T motor

2.4 GHz TQi? radio system with cruise control

High-quality maintenance tools

What You'll Need:

Batteries: TRX-4 accepts a wide range of NiMH batteries (4 to 7 cells) and LiPo batteries (2S to 3S).

Charger

AA alkaline batteries: Four AA batteries for the transmitter.
