Hobbywing Xerun 4268SD Brushless Motor G3 2200kV Off-Road
The Xerun 4268 G3 motor offers 1/8 off-road RC model drivers a lot of driving fun with even better performance.This is due to the improved design and efficiency in fighting against generated heat.Because compared to the predecessor engines of the G2, this has increased by 6%, which significantly reduces heat generation.
Sensor mode 100%
With the integrated chip, the Xerun G3 motor can also be recognized by the controllers. Hobbywing Xerun XR8.This combination results in a drive system that is 100% sensor-controlled.Furthermore, the Hall sensor system ensures clean and stable operation in sensor mode.
Note: If the engine is connected to other controllers, there is no guarantee that the sensor mode is active.
Turbo synchronization technology
When used with an XERUN XR8 series controller, you can also activate "Turbo Timing".This is already being used very successfully in the 1/10 scale road area and also unleashes the motor's last power reserves.
Characteristics
- Low heat development
- Low retention rate
- High quality materials and excellent craftsmanship.
- Easy installation
- Dustproof according to the IP5X standard (1900 kV, 2200 kV, and 2250 kV).
Technical specifications:
| Scale: | 1/8 |
| Type: | Brushless with sensor |
| Power: | 2200kV |
| Standby power consumption: | 4.1A |
| LiPo cell count: | 2-6S |
| Number of poles: | Room |
| Length: | 67.8 mm |
| Diameter: | 42 mm |
| Shaft diameter: | 5 mm |
| Weight: | 285 g |
| Synchronization: | 20-40 degrees (adjustable) |
| Commitment | 1/8 off-road vehicle |
content
1x motor
1x sensor cable
1x user manual (English)
