Fácil montaje / desmontaje
Facil mantenimiento
Disposición centralizada y compacta de piezas en el chasis
Piezas de alto rendimiento ultra duraderas
Chasis y brazos de suspensión MCD de quinta generación
Sofisticada mecánica 4WD impulsada por eje a tiempo completo
Eje y eje de transmisión cromados ultra reforzados
Sistema de malla de engranajes fácil
Bandeja electrónica de una pieza fácilmente extraíble
Chasis de aleación de aviones 7075 T6 liviano, anodizado y mecanizado por CNC
Espoletas largas reforzadas
Protectores laterales aerodinámicos sólidos y duraderos
Cajas de diferenciales de material compuesto delantero, trasero y central fácilmente extraíbles
Sistema de frenos ajustable delantero y trasero ultraduradero
Ranura de servo solo para freno trasero
Torres delanteras y traseras de aleación ligera 7075 para aeronaves de 5 mm
Agujeros de montaje de choque múltiples optimizados
Amortiguadores de aleación extendidos en espiral con sistema High Pressurized Cell ?
Engranajes de transmisión de acero ultra endurecido
Barras estabilizadoras de doble rodamiento de bolas
Parachoques delantero y difusor trasero de poliamida sin efecto de estrés
Juntas de copa de bola de acero ultra duraderas
Sistema de ventilación de aire Super-Cooling V5
Filtros de aire Viper Racing con espuma de doble capa y manguera termoplástica
Escape de alto rendimiento Barracuda G
CG ajustable
Distribución de peso ajustable
Tanque de combustible moldeado con separadores que absorben las vibraciones
Diferenciales frontales con bloqueo automático de rampa seleccionable de 90 ° a 120 °
Barra de bloqueo sólida central
Diferencial planetario trasero
Accesorios de cuerpo completamente compuestos
Bota del eje de transmisión
|
| ON-ROAD COMPARISON CHART |
| Part (Order Code) |
Competition |
Pro |
FT-R |
Ultimate |
|
Short Chassis |
Long Chassis (MAX) |
| Chassis |
5083 Alloy - Short |
7075 Alloy - CNC Machined - Anodized (400103A) |
7075 Alloy - CNC Machined - Anodized (400103A) |
7077 Alloy - CNC Machined - Anodized (400103A) |
| Barracuda G Performance Exaust Set (750601X) |
OPT |
STD |
STD |
STD |
| Clutch Bell Carrier |
Composite |
Alloy (415502A) |
Alloy (415502A) |
Alloy (415502A) |
| Engine Clutch House Alloy (415701A) |
OPT |
OPT |
OPT |
STD |
| DBB Ackerman Plate Standard 8mm (380203A) |
OPT |
STD |
STD |
STD |
| Front Diff. |
Planetary F/R |
LSD F/R (200101X) |
LSD F/R (200101X) |
LSD F/R (200103X) |
| Center Diff. |
Solid Lock Bar |
Solid Lock Bar |
LSD Center (200201X) |
LSD Center (200203X) |
| Rear Diff. |
Planetary F/R |
Planetary F/R |
Planetary F/R |
LSD F/R (200103X) |
| Diff. Case |
Composite |
Composite |
Composite |
Alloy (200402A) |
| Front Diff. House Inner |
Composite |
Composite |
Composite |
Alloy (415102A) |
| Rear Diff. House Inner |
Composite |
Composite |
Alloy (415102A) |
Alloy (415102A) |
| Center Diff.Holder Set |
Composite |
Composite |
Alloy (415202A) |
Alloy (415202A) |
| Front Wishbone Alloy (300104A) |
OPT |
OPT |
STD |
STD |
| Front Hub L/R |
Composite |
Composite |
Alloy (300603A) |
Alloy (300603A) |
| Rear Hub L/R |
Composite |
Composite |
Alloy (300604A) |
Alloy (300604A) |
| L/R Caster Block |
Composite(6°) |
Composite(6°) |
0° Alloy (300704A) |
0°, ±4° Alloy (300705X) |
| Pro-Bite Racing Clutch (290101X) |
OPT |
OPT |
OPT |
STD |
| Turnbuckle Set |
Steel |
Steel |
Steel |
Alloy (301204X) |
| Shock Absorbers |
Composite |
Alloy (320103X) |
Alloy (320103X) |
Alloy (320107X) |
| Upper Shock Absorber Joint Cup |
Composite |
Composite |
Composite |
Alloy (320502A) |
| Lower Shock Absorber M5 Joint |
Composite |
Composite |
Composite |
Alloy (320503A) |
| M8 Upper Wishbone Rose Joint L/R Thread |
Composite |
Composite |
Alloy (340102A) |
Alloy (340102A) |
| Servo Saver Upper Arm |
Composite |
Composite |
Composite |
Alloy (380102A) & Composite |
| Steering Servo Turnbuckle |
Steel |
Steel |
Steel |
Alloy (381002A) |
| Brake Plate |
Composite |
Composite |
Alloy (415302A) |
Alloy (415302A) |
| Lay Shaft Carrier |
Composite |
Alloy (415402A) |
Alloy (415402A) |
Alloy (415402A) |
| Rear Upper Stiffener Alloy (446201A) |
OPT* |
OPT* |
STD |
STD |
| Front Stiffener |
Composite |
Composite |
Composite |
Alloy (445102A) |
| Rear Stiffener |
Composite |
Alloy (445202A) |
Alloy (445202A) |
Alloy (445202A) |
| Upper Stiffener Alloy |
OPT** |
OPT** |
Alloy (446101A) |
Alloy (446101A) |
| Diff.House-Stiffener Spacer |
Composite |
Composite |
Alloy (460102A) |
Alloy (460102A) |
| Carburetor / AirFilter Venturi |
Composite |
Composite |
Alloy (725302A) |
Alloy (725302A) |
| Engine Insulator Alloy G230-G290 (726002A) |
OPT |
OPT |
OPT |
STD |
| Radio/Servo Tray - Hydraulic Brake Compatible (930301X) |
OPT |
OPT |
OPT |
STD |
| Brake Disc |
Spring Steel |
Spring Steel |
Light Weight ABS (260102S) |
Light Weight ABS (260102S) |
| Front Wishbone Holder Set |
Composite |
Alloy (300203A) |
Alloy (300203A) |
Alloy (300203A) |
| Rear Wishbone Holder Set |
Composite |
Alloy (300303A) |
Alloy (300303A) |
Alloy (300303A) |
| Anti-Roll Bar Set F/R 3.5mm (360101X) |
OPT |
STD |
STD |
STD |
| Front Tower |
Alloy 5mm |
Alloy 5mm (430303A) |
Alloy 5mm (430303A) |
Alloy 5mm (430303A) |
| Rear Tower |
Alloy 5mm |
Alloy 5mm (430403A) |
Alloy 5mm (430403A) |
Alloy 5mm (430403A) |
| *Required for assembly: 446201A, 415402A and 415302A |
| **Required for assembly: 446101A and 446301A |
Length : 1100 mm
Width : 480 mm
Overall height : 270 mm
Ground clearance : 25-42 mm
Weight : 14.2kg
Wheelbase : 610-620 mm (adjustable)
Trackwidth : 410mm
Chassis material : 7075 Anodized T6 Alloy (4mm)
Suspension : Non-parallel non-line independent
Caster angle : 8°(6° - 10°(total caster) adjustable)
Camber angle : Adjustable
Toe angle : In-board and out-board adjustable
Anti-squat : 3°(adjustable)
Rear-squat : 5°
Dive, Anti-dive : 6°-10°(adjustable)
Kick-up : 6°-10°(adjustable)
Shock absorber : Coil-over Oil-filled Internal High Pressure Cell
Transmission : Full-Time 4WD 3-Diff Shaft Driven
Gear ratio : 7,2:1 (18 available 7,2:1 to 10,67:1)
Tyre size : 65 x 160 mm
|
