Cargador AC/DC Q4AC Lipo 1-4S 5A cuatro toolkit

The Q4AC is a four-channel charger with balancer function and IPS display. Menu navigation via the roller makes operation simple and straightforward.

Features:

Max. 50W charging power on all four channels and a maximum of 5A charging current

Max. 5W discharge power per channel at around 2A

Adjustable cut-off voltage for lithium batteries

Store 5 battery information and 3 power supply information for faster handling

Multilingual user interface

Firmware upgrade via USB

Technical Specifications:

Input Voltage:AC: 100-240V, max. 1.5A

DC: 10-18V, max. 20A

Charging Power:DC: 0.1-5A, 50Wx4

AC: 0.1-5A, 50Wx2

AC: 0.1-5A, 25Wx4

Discharging Power:0.1-2A, 5Wx4

Charging Accuracy:<0.005V

Balance Current:240mA, 2-4S

Cells: LiPo/LiFe/LiIon/LiHV1-4S

Cells: NiMH/NiCd1-10S

Pb Battery Voltage:1-8S

Voltage:1.0V-5.0V, 1-4S

Display:IPS 3.5'' 480x320px

Dimensions:150x112x36.5mm

Weight:450g

Delivery:

1x Q4AC Charger

1x Power cable

1x USB cable

1x Display protection

1x Manual
